Signal Devices
Buzzers, Indicators & Sirens
Made in the USA
Board Mount Buzzers
- Circuito DC incluido
- Para piezas selladas, incluie el sufijo "S"
- 15 nuevos sonidos de advertencia únicos
- dB Distancia = 30cm
- RoHS aprobado
Aquí encontrará algunos de los modelos más populares para esta línea, pero hay más. Clica en el botón de abajo para obtener un catálogo completo.
| Model | Sound Type | Frequency | Min. Volt | Max. Volt | Volt Type | Max. db | Size |
|---|---|---|---|---|---|---|---|
| MSE14LCH2 | Bird Chirp | 4.5-3.2kHz | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LCH2S | Bird Chirp | 4.5-3.2kHz | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LCM1 | Chime | 3900 | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LCM1S | Chime | 3900 | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LCM3 | Fast Chime | 3900 | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LCM3S | Fast Chime | 3900 | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LDD7 | Ding Dong | 4.3-3.4kHz | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LDD7S | Ding Dong | 4.3-3.4kHz | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LDP2 | Fast Double Pulse | 3900 | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LDP2S | Fast Double Pulse | 3900 | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LDP3 | Slow Double Pulse | 3900 | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LDP3S | Slow Double Pulse | 3900 | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LDT7 | Fast Warble | 3.9-3.8kHz | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LDT7S | Fast Warble | 3.9-3.8kHz | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LDT8 | Slow Warble | 3.9-3.8kHz | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LDT8S | Slow Warble | 3.9-3.8kHz | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LPS1 | Short Pulse | 3900 | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LPS1S | Short Pulse | 3900 | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LSN2 | Slow Siren | 2.1-5.9kHz | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LSN2S | Slow Siren | 2.1-5.9kHz | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LSN3 | Fast Siren | 2.1-5.9kHz | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LSN3S | Fast Siren | 2.1-5.9kHz | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LSU2 | Fast Speed Up | 3900 | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LSU2S | Fast Speed Up | 3900 | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LTT3 | Telephone Ringer | 3.0-3.7kHz | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LTT3S | Telephone Ringer | 3.0-3.7kHz | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LWH1 | Fast Whooping | 2.1-5.8kHz | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LWH1S | Fast Whooping | 2.1-5.8kHz | 7 | 14 | DC | 95 | 23x14mm |
| MSE14LWH2 | Slow Whooping | 2.1-5.8kHz | 7 | 14 | DC | 95 | 23x14mm |
Crosswalk Alarms
Aplicaciones de cruce peatonal
Sonido de Cuco: Norte-Sur
Sonido de Chirrido: Este-Oeste
120 Vac
Cabe en abertura de 30mm
dB Distancia = 2 pies (60cm)
Sonido de Cuco: Norte-Sur
Sonido de Chirrido: Este-Oeste
120 Vac
Cabe en abertura de 30mm
dB Distancia = 2 pies (60cm)
Clica en el botón de abajo para obtener un catálogo completo de aplicaciones.
| Model | Sound Type | Frequency | Min. Volt | Max. Volt | Volt Type | Max. db | Size |
|---|---|---|---|---|---|---|---|
| VSB110-1 | Cuckoo | 1000 | 120 | 120 | AC Only | 85 | 1.69x3in |
| VSB110-2 | Chirp | 2000 | 120 | 120 | AC Only | 85 | 1.69x3in |
Hazardous Locations Alarms
- Clase I Div II Grupos A, B, C y D
- cUL aprobado
- NEMA 4X
- Cabe en el agujero del panel de 30 mm
- dB Distancia = 2 pies (60cm)
Aquí encontrará algunos de los modelos más populares para esta línea, pero hay más. Clica en el botón de abajo para obtener un catálogo completo.
| Model | Sound Type | Frequency | Min. Volt | Max. Volt | Volt Type | Max. db | Size |
|---|---|---|---|---|---|---|---|
| SCH105R | Continuous | 2900 | 1 | 5 | DC | 83 | 1.69x1.41in |
| SCH110NJR | Slow Pulse | 2900 | 30 | 120 | AC/DC | 98 | 1.69x1.41in |
| SCH110NPR | Fast Pulse | 2900 | 30 | 120 | AC/DC | 101 | 1.69x1.41in |
| SCH110NR | Continuous | 2900 | 30 | 120 | AC/DC | 100 | 1.69x1.41in |
| SCH110PR | Fast Pulse | 2900 | 30 | 120 | AC/DC | 89 | 1.69x1.41in |
| SCH110R | Continuous | 2900 | 30 | 120 | AC/DC | 92 | 1.69x1.41in |
| SCH250PR | Fast Pulse | 2900 | 60 | 250 | AC/DC | 86 | 1.69x1.41in |
| SCH250R | Continuous | 2900 | 60 | 250 | AC/DC | 88 | 1.69x1.41in |
| SCH307NR | Continuous | 2900 | 3 | 7 | DC | 97 | 1.69x1.41in |
| SCH416R | Continuous | 2900 | 4 | 16 | DC | 89 | 1.69x1.41in |
| SCH616CPR | Chime | 2900 | 6 | 16 | DC | 81 | 1.69x1.41in |
| SCH616NPR | Fast Pulse | 2900 | 6 | 16 | DC | 102 | 1.69x1.41in |
| SCH616NR | Continuous | 2900 | 6 | 16 | DC | 105 | 1.69x1.41in |
| SCH628ANPR | Fast Pulse | 2900 | 6 | 28 | AC/DC | 103 | 1.69x1.41in |
| SCH628ANR | Continuous | 2900 | 6 | 28 | AC/DC | 103 | 1.69x1.41in |
| SCH628AR | Continuous | 2900 | 6 | 28 | AC/DC | 89 | 1.69x1.41in |
| SCH628DR | Continuous | 1900 | 6 | 28 | DC | 78 | 1.69x1.41in |
| SCH628NLR | Continuous | 2900 | 6 | 28 | DC | 97 | 1.69x1.41in |
| SCH628NR | Continuous | 2900 | 6 | 28 | DC | 97 | 1.69x1.41in |
| SCH628PR | Fast Pulse | 2900 | 6 | 28 | DC | 89 | 1.69x1.41in |
| SCH628R | Continuous | 2900 | 6 | 28 | DC | 90 | 1.69x1.41in |
| SCH648AR | Continuous | 2900 | 10 | 48 | AC/DC | 91 | 1.69x1.41in |
| SCH648R | Continuous | 2900 | 10 | 48 | DC | 91 | 1.69x1.41in |
Military-Grade Rugged Alarms
- Código de jaula 90201
- Rango de temperatura de funcionamiento de -40 ° C a 85 ° C
- Cabe en abertura de 30mm
- Pruebas ambientales extendidas
- dB Distancia = 2 pies (60cm)
Aquí encontrará algunos de los modelos más populares para esta línea, pero hay más. Clica en el botón de abajo para obtener un catálogo completo.
| Model | Sound Type | Frequency | Min. Volt | Max. Volt | Volt Type | Max. db | Size |
|---|---|---|---|---|---|---|---|
| SC110M | Continuous | 2900 | 30 | 120 | AC/DC | 92 | 1.69x1.9in |
| SC110MH | Continuous | 4500 | 30 | 120 | AC/DC | 92 | 1.69x1.9in |
| SC110MN | Continuous | 2900 | 30 | 120 | AC/DC | 100 | 1.69x1.9in |
| SC250M | Continuous | 2900 | 60 | 250 | AC/DC | 88 | 1.69x1.9in |
| SC616MN | Continuous | 2900 | 6 | 16 | DC | 105 | 1.69x1.41in |
| SC616MPU | Dual Mode- C/FP | 2900 | 6 | 16 | DC | 88 | 1.69x1.41in |
| SC628M | Continuous | 2900 | 6 | 28 | DC | 90 | 1.69x1.41in |
| SC628MA | Continuous | 2900 | 6 | 28 | AC/DC | 88 | 1.69x1.9in |
| SC628MAH | Continuous | 4500 | 6 | 28 | AC/DC | 89 | 1.69x1.9in |
| SC628MD | Continuous | 1900 | 6 | 28 | DC | 78 | 1.69x1.41in |
| SC628MH | Continuous | 4500 | 6 | 28 | DC | 89 | 1.69x1.41in |
| SC628MHP | Fast Pulse | 4500 | 6 | 28 | DC | 89 | 1.69x1.9in |
| SC628MN | Continuous | 2900 | 6 | 28 | DC | 97 | 1.69x1.41in |
| SC628MNP | Fast Pulse | 2900 | 6 | 28 | DC | 95 | 1.69x1.9in |
| SC628MP | Fast Pulse | 2900 | 6 | 28 | DC | 89 | 1.69x1.9in |
| SC628MW | Fast Warble | 2900 | 6 | 28 | DC | 89 | 1.69x1.9in |
| SC648M | Continuous | 2900 | 10 | 48 | DC | 80 | 1.69x1.41in |
| SC648MA | Continuous | 2900 | 10 | 48 | AC/DC | 89 | 1.69x1.9in |
| SC648MAH | Continuous | 4500 | 10 | 48 | AC/DC | 93 | 1.69x1.9in |
| SC648MAN | Continuous | 2900 | 10 | 48 | AC/DC | 104 | 1.69x1.9in |
| SC648MD | Continuous | 1900 | 10 | 48 | DC | 79 | 1.69x1.41in |
30mm Alarms with LED Indicators
- Se adapta en abertura de 30mm
- Luz LED roja intermitente
- Sonido continuo
- dB Distancia = 2 pies (60cm)
- RoHS
Aquí encontrará algunos de los modelos más populares para esta línea, pero hay más. Clica en el botón de abajo para obtener un catálogo completo.
| Model | Sound Type | Frequency | Min. Volt | Max. Volt | Volt Type | Max. db | RoHs | UL | Size |
|---|---|---|---|---|---|---|---|---|---|
| LSC110NR | Continuous | 2900 | 30 | 120 | AC/DC | 98 | Yes | No | 1.69x1.41in |
| LSC250NR | Continuous | 2900 | 60 | 250 | AC/DC | 87 | Yes | No | 1.69x1.41in |
| LSC616NR | Continuous | 2900 | 6 | 16 | DC | 95 | Yes | No | 1.69x1.41in |
| LSC628ANR | Continuous | 2900 | 9 | 28 | AC/DC | 99 | Yes | No | 1.69x1.41in |
30mm Alarms with Wires
- Cabe en abertura de 30mm
- Terminación de cable
- dB Distancia = 2 pies (60cm)
Aquí encontrará algunos de los modelos más populares para esta línea, pero hay más. Clica en el botón de abajo para obtener un catálogo completo.
| Model | Sound Type | Frequency | Min. Volt | Max. Volt | Volt Type | Max. db | RoHs | UL | Size |
|---|---|---|---|---|---|---|---|---|---|
| SC616NLR | Continuous | 2900 | 6 | 16 | DC | 105 | Yes | Yes | 1.69x1.41in |
| SC628LR | Continuous | 2900 | 6 | 28 | DC | 90 | Yes | Yes | 1.69x1.41in |
| SC628NLR | Continuous | 2900 | 6 | 28 | DC | 97 | Yes | Yes | 1.69x1.41in |
| SCE016XD3MG1W | Multi-Tone | 2900 | 6 | 16 | DC | 105 | Yes | Yes | 1.69x1.41in |
30mm Alarms with Flat Blade Terminals
- Cabe en el abertura de 30mm
- Terminal de conexión rápida estándar de 0.25 "
- La mayoría de los modelos están aprobados por cUL
- NEMA 4X con P/N ACC03
- dB Distancia = 2 pies (60cm)
Aquí encontrará algunos de los modelos más populares para esta línea, pero hay más. Clica en el botón de abajo para obtener un catálogo completo.
| Model | Sound Type | Frequency | Min. Volt | Max. Volt | Volt Type | Min. db | Max. db | Size |
|---|---|---|---|---|---|---|---|---|
| SC616CP-BTR | Chime | 2900 | 6 | 16 | DC | 74 | 81 | 1.69x1.41in |
| SC616J-1R | Slow Pulse | 2900 | 6 | 16 | DC | 75 | 84 | 1.69x1.41in |
| SC616N-BTR | Continuous | 2900 | 6 | 16 | DC | 95 | 105 | 1.69x1.41in |
| SC616NJ-BTR | Slow Pulse | 2900 | 6 | 16 | DC | 92 | 101 | 1.69x1.41in |
| SC616NP-BTR | Fast Pulse | 2900 | 6 | 16 | DC | 91 | 102 | 1.69x1.41in |
| SC616P-1R | Fast Pulse | 2900 | 6 | 16 | DC | 75 | 84 | 1.69x1.41in |
| SC628AN-BTR | Continuous | 2900 | 6 | 28 | AC/DC | 88 | 101 | 1.69x1.41in |
| SC628-BTR | Continuous | 2900 | 6 | 28 | DC | 80 | 91 | 1.69x1.41in |
| SC628D-BTR | Continuous | 1900 | 6 | 28 | DC | 67 | 80 | 1.69x1.41in |
| SC628H-BTR | Continuous | 4500 | 6 | 28 | DC | 78 | 89 | 1.69x1.41in |
| SC628N-BTR | Continuous | 2900 | 6 | 28 | DC | 86 | 97 | 1.69x1.41in |
| SC628P-BTR | Fast Pulse | 2900 | 6 | 28 | DC | 79 | 89 | 1.69x1.41in |
| SCE016LD3MP1F | Medium Pulse | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016XD3MG5F | Multi-Tone | 2900 | 6 | 16 | DC | 85 | 105 | 1.69x1.41in |
| SCE028MD3MP1F | Medium Pulse | 2900 | 16 | 28 | DC | 75 | 85 | 1.69x1.41in |
| Fast Pulse | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in | |
| SCE016LD3MG3B | Multi-Tone | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3MG4B | Multi-Tone | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3MG5B | Multi-Tone | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3MP1B | Medium Pulse | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3PS1B | Short Pulse | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3QP1B | Chirp | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3SD5B | 1 Min Double Pulse | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3SP1B | Slow Pulse | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3SR3B | Fast Siren | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3SR4B | Slow Siren | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3SS1B | 1 Min Continuous | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3SU1B | Slow Speed Up | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3SU2B | Fast Speed Up | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
30mm Alarms with Terminal Block Connection
- Cabe en el abertura del panel de 30mm
- Aprobado por cUL
- NEMA 4X cuando con P/N ACC03
- dB Distancia = 2 pies (60cm)
Aquí encontrará algunos de los modelos más populares para esta línea, pero hay más. Clica en el botón de abajo para obtener un catálogo completo.
| Model | Sound Type | Frequency | Min. Volt | Max. Volt | Volt Type | Min. db | Max. db | Size |
|---|---|---|---|---|---|---|---|---|
| SCE016LD2CTB | Continuous | 2000 | 6 | 16 | DC | 85 | 96 | 1.69x1.41in |
| SCE016LD2DP2B | Fast Double Pulse | 2000 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD2DP3B | Slow Double Pulse | 2000 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD2FP1B | Fast Pulse | 2000 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD2MP1B | Medium Pulse | 2000 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD2SP1B | Slow Pulse | 2000 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3CK1B | Click Pulse | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3CM1B | Chime | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3CTB | Continuous | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3DL1B | 10 S Delay Cont | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3DP2B | Fast Double Pulse | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3DP3B | Slow Double Pulse | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3DT7B | Fast Warble | 2950 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3DT8B | Slow Warble | 2950 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3ED5B | 10 S Delay Double | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3FP1B | Fast Pulse | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3MG3B | Multi-Tone | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3MG4B | Multi-Tone | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3MG5B | Multi-Tone | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3MP1B | Medium Pulse | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3PS1B | Short Pulse | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3QP1B | Chirp | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3SD5B | 1 Min Double Pulse | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3SP1B | Slow Pulse | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3SR3B | Fast Siren | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3SR4B | Slow Siren | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3SS1B | 1 Min Continuous | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3SU1B | Slow Speed Up | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| SCE016LD3SU2B | Fast Speed Up | 2900 | 6 | 16 | DC | 85 | 95 | 1.69x1.41in |
| Model | Sound Type | Frequency | Min. Volt | Max. Volt | Volt Type | Min. db | Max. db | Size |
|---|---|---|---|---|---|---|---|---|
| SCE016XD3MG3B | Multi-Tone | 2900 | 6 | 16 | DC | 95 | 105 | 1.69x1.41in |
| SCE016XD3MG4B | Multi-Tone | 2900 | 6 | 16 | DC | 95 | 105 | 1.69x1.41in |
| SCE016XD3MG5B | Multi-Tone | 2900 | 6 | 16 | DC | 95 | 105 | 1.69x1.41in |
| SCE016XD3MP1B | Medium Pulse | 2900 | 6 | 16 | DC | 95 | 105 | 1.69x1.41in |
| SCE016XD3PS1B | Short Pulse | 2900 | 6 | 16 | DC | 95 | 105 | 1.69x1.41in |
| SCE016XD3QP1B | Chirp | 2900 | 6 | 16 | DC | 95 | 105 | 1.69x1.41in |
| SCE016XD3SD5B | 1 Min Double Pulse | 2900 | 6 | 16 | DC | 95 | 105 | 1.69x1.41in |
| SCE016XD3SP1B | Slow Pulse | 2900 | 6 | 16 | DC | 95 | 105 | 1.69x1.41in |
| SCE016XD3SS1B | 1 Min Continuous | 2900 | 6 | 16 | DC | 95 | 105 | 1.69x1.41in |
| SCE016XD3SU1B | Slow Speed Up | 2900 | 6 | 16 | DC | 95 | 105 | 1.69x1.41in |
| SCE016XD3SU2B | Fast Speed Up | 2900 | 6 | 16 | DC | 95 | 105 | 1.69x1.41in |
| SCE028LA2CT1B | Continuous | 2000 | 16 | 28 | AC/DC | 85 | 95 | 1.69x1.41in |
| SCE028LA2DP2B | Fast Double Pulse | 2000 | 16 | 28 | AC/DC | 85 | 95 | 1.69x1.41in |
| SCE028LA2DP3B | Slow Double Pulse | 2000 | 16 | 28 | AC/DC | 85 | 95 | 1.69x1.41in |
| SCE028LA2FP1B | Fast Pulse | 2000 | 16 | 28 | AC/DC | 85 | 95 | 1.69x1.41in |
| SCE028LA2MP1B | Medium Pulse | 2000 | 16 | 28 | AC/DC | 85 | 95 | 1.69x1.41in |
| SCE028LA2SP1B | Slow Pulse | 2000 | 16 | 28 | AC/DC | 85 | 95 | 1.69x1.41in |
| SCE028LA3CK1B | Click Pulse | 2900 | 16 | 28 | AC/DC | 85 | 95 | 1.69x1.41in |
| SCE028LA3CM1B | Chime | 2900 | 16 | 28 | AC/DC | 85 | 95 | 1.69x1.41in |
| SCE028LA3CTB | Continuous | 2900 | 16 | 28 | AC/DC | 85 | 95 | 1.69x1.41in |
| SCE028LA3DL1B | 10 S Delay Cont | 2900 | 16 | 28 | AC/DC | 85 | 95 | 1.69x1.41in |
| SCE028LA3DP2B | Fast Double Pulse | 2900 | 16 | 28 | AC/DC | 85 | 95 | 1.69x1.41in |
| SCE028LA3DP3B | Slow Double Pulse | 2900 | 16 | 28 | AC/DC | 85 | 95 | 1.69x1.41in |
| SCE028LA3DT7B | Fast Warble | 2950 | 16 | 28 | AC/DC | 85 | 95 | 1.69x1.41in |
| SCE028LA3DT8B | Slow Warble | 2950 | 16 | 28 | AC/DC | 85 | 95 | 1.69x1.41in |
| SCE028LA3ED5B | 10 S Delay Double | 2900 | 16 | 28 | AC/DC | 85 | 95 | 1.69x1.41in |
| SCE028LA3FP1B | Fast Pulse | 2900 | 16 | 28 | AC/DC | 85 | 95 | 1.69x1.41in |
| SCE028LA3MP1B | Medium Pulse | 2900 | 16 | 28 | AC/DC | 85 | 95 | 1.69x1.41in |
| SCE028LA3PS1B | Short Pulse | 2900 | 16 | 28 | AC/DC | 85 | 95 | 1.69x1.41in |
30mm Alarms with Screw Terminals
- Cabe en el abertura del panel de 30mm
- Ver tabla/hoja de datos para la aprobación cUL
- NEMA 4X cuando con P/N ACC03
- dB Distancia = 2 pies (60cm)
Aquí encontrará algunos de los modelos más populares para esta línea, pero hay más. Clica en el botón de abajo para obtener un catálogo completo.
| Model | Sound Type | Frequency | Min. Volt | Max. Volt | Volt Type | Max. db | RoHs | UL | Size |
|---|---|---|---|---|---|---|---|---|---|
| SC105R | Continuous | 2900 | 1 | 5 | DC | 83 | Yes | Yes | 1.69x1.41in |
| SC110DJR | Slow Pulse | 1900 | 30 | 120 | AC/DC | 78 | Yes | Yes | 1.69x1.41in |
| SC110DPR | Fast Pulse | 1900 | 30 | 120 | AC/DC | 77 | Yes | Yes | 1.69x1.41in |
| SC110DR | Continuous | 1900 | 30 | 120 | AC/DC | 80 | Yes | Yes | 1.69x1.41in |
| SC110EJR | Slow Pulse | 1900 | 30 | 120 | AC/DC | 73 | Yes | No | 1.69x1.41in |
| SC110EPR | Fast Pulse | 1900 | 30 | 120 | AC/DC | 73 | Yes | No | 1.69x1.41in |
| SC110ER | Continuous | 1900 | 30 | 120 | AC/DC | 67 | Yes | No | 1.69x1.41in |
| SC110FJR | Slow Pulse | 2900 | 30 | 120 | AC/DC | 84 | Yes | No | 1.69x1.41in |
| SC110FKR | Short Pulse | 2900 | 30 | 120 | AC/DC | 69 | Yes | No | 1.69x1.41in |
| SC110FPR | Fast Pulse | 2900 | 30 | 120 | AC/DC | 85 | Yes | No | 1.69x1.41in |
| SC110FR | Continuous | 2900 | 30 | 120 | AC/DC | 72 | Yes | No | 1.69x1.41in |
| SC110HJR | Slow Pulse | 4500 | 30 | 120 | AC/DC | 87 | Yes | No | 1.69x1.41in |
| SC110HPR | Fast Pulse | 4500 | 30 | 120 | AC/DC | 87 | Yes | No | 1.69x1.41in |
| SC110HR | Continuous | 4500 | 30 | 120 | AC/DC | 92 | Yes | Yes | 1.69x1.41in |
| SC110JR | Slow Pulse | 2900 | 30 | 120 | AC/DC | 89 | Yes | Yes | 1.69x1.41in |
| SC110JWR | Slow Warble | 2900 | 30 | 120 | AC/DC | 83 | Yes | No | 1.69x1.41in |
| SC110KR | Short Pulse | 2900 | 30 | 120 | AC/DC | 85 | Yes | Yes | 1.69x1.41in |
| SC110NJR | Slow Pulse | 2900 | 30 | 120 | AC/DC | 98 | Yes | Yes | 1.69x1.41in |
| SC110NPR | Fast Pulse | 2900 | 30 | 120 | AC/DC | 101 | Yes | Yes | 1.69x1.41in |
| SC110NR | Continuous | 2900 | 30 | 120 | AC/DC | 100 | Yes | Yes | 1.69x1.41in |
| SC110PR | Fast Pulse | 2900 | 30 | 120 | AC/DC | 89 | Yes | Yes | 1.69x1.41in |
| SC110QR | Chirp | 2900 | 30 | 120 | AC Only | 99 | Yes | Yes | 1.69x1.41in |
| SC110R | Continuous | 2900 | 30 | 120 | AC/DC | 92 | Yes | Yes | 1.69x1.41in |
| SC2036CPR | Chime | 1000 | 20 | 36 | DC | 82 | Yes | No | 1.69x1.9in |
| SC208NR | Continuous | 2900 | 2 | 8 | DC | 104 | Yes | No | 1.69x1.41in |
| SC250DJR | Slow Pulse | 1900 | 60 | 250 | AC/DC | 75 | Yes | No | 1.69x1.41in |
| SC250DPR | Fast Pulse | 1900 | 60 | 250 | AC/DC | 75 | Yes | No | 1.69x1.41in |
| SC250DR | Continuous | 1900 | 60 | 250 | AC/DC | 77 | Yes | Yes | 1.69x1.41in |
| SC250EJR | Slow Pulse | 1900 | 60 | 250 | AC/DC | 73 | Yes | No | 1.69x1.41in |
| Model | Sound Type | Frequency | Min. Volt | Max. Volt | Volt Type | Max. db | RoHs | UL | Size |
|---|---|---|---|---|---|---|---|---|---|
| SC628JWR | Slow Warble | 2900 | 6 | 28 | DC | 88 | Yes | No | 1.69x1.41in |
| SC628KR | Short Pulse | 2900 | 6 | 28 | DC | 88 | Yes | No | 1.69x1.41in |
| SC628NDPR | Fast Pulse | 2000 | 10 | 28 | DC | 96 | Yes | No | 1.69x1.9in |
| SC628NDR | Continuous | 2000 | 9 | 28 | DC | 98 | Yes | No | 1.69x1.9in |
| SC628NJR | Slow Pulse | 2900 | 6 | 28 | DC | 96 | Yes | No | 1.69x1.41in |
| SC628NPR | Fast Pulse | 2900 | 6 | 28 | DC | 95 | Yes | No | 1.69x1.41in |
| SC628NR | Continuous | 2900 | 6 | 28 | DC | 97 | Yes | Yes | 1.69x1.41in |
| SC628PR | Fast Pulse | 2900 | 6 | 28 | DC | 89 | Yes | Yes | 1.69x1.41in |
| SC628R | Continuous | 2900 | 6 | 28 | DC | 90 | Yes | Yes | 1.69x1.41in |
| SC628WR | Fast Warble | 2900 | 6 | 28 | DC | 89 | Yes | No | 1.69x1.41in |
| SC630JWR | Slow Warble | 1.8-2.8kHz | 9 | 30 | DC | 85 | Yes | No | 1.69x1.41in |
| SC648ADJR | Slow Pulse | 1900 | 10 | 48 | AC/DC | 77 | Yes | No | 1.69x1.41in |
| SC648ADPR | Fast Pulse | 1900 | 10 | 48 | AC/DC | 78 | Yes | No | 1.69x1.41in |
| SC648ADR | Continuous | 1900 | 10 | 48 | AC/DC | 79 | Yes | Yes | 1.69x1.41in |
| SC648AER | Continuous | 1900 | 10 | 48 | AC/DC | 74 | Yes | No | 1.69x1.41in |
| SC648AHR | Continuous | 4500 | 10 | 48 | AC/DC | 88 | Yes | No | 1.69x1.41in |
| SC648AJR | Slow Pulse | 2900 | 10 | 48 | AC/DC | 89 | Yes | Yes | 1.69x1.41in |
| SC648AKR | Short Pulse | 2900 | 10 | 48 | AC/DC | 90 | Yes | No | 1.69x1.41in |
| SC648ANJR | Slow Pulse | 2900 | 10 | 48 | AC/DC | 104 | Yes | No | 1.69x1.41in |
| SC648ANPR | Fast Pulse | 2900 | 10 | 48 | AC/DC | 103 | Yes | No | 1.69x1.41in |
| SC648ANR | Continuous | 2900 | 10 | 48 | AC/DC | 105 | Yes | Yes | 1.69x1.41in |
| SC648APR | Fast Pulse | 2900 | 10 | 48 | AC/DC | 87 | Yes | Yes | 1.69x1.41in |
| SC648AR | Continuous | 2900 | 10 | 48 | AC/DC | 91 | Yes | Yes | 1.69x1.41in |
| SC648CPNR | Chime | 2900 | 10 | 48 | DC | 96 | Yes | No | 1.69x1.41in |
| SC648DR | Continuous | 1900 | 10 | 48 | DC | 80 | Yes | Yes | 1.69x1.41in |
| SC648HR | Continuous | 4500 | 10 | 48 | DC | 89 | Yes | No | 1.69x1.41in |
| SC648NDR | Continuous | 2000 | 12 | 48 | DC | 97 | Yes | No | 1.69x1.9in |
| SC648R | Continuous | 2900 | 10 | 48 | DC | 91 | Yes | Yes | 1.69x1.41in |
| SC648S | Fast Siren | 1900-2900 | 10 | 48 | DC | 93 | No | Yes | 1.69x1.9in |
Industrial Indicators with LEDs
- Alarma audible + luz LED
- Archivo UL # NKCR2.E478987
- Archivo cUL # NKCR8.E478987
- NEMA 4X, 3R y 12
- dB Distancia = 2 pies (60cm)
- Opcional: el sonido puede apagarse después de 15 o 30 segundos y el LED continúa parpadeando
- Patente No. 9165440
Clica en el botón de abajo para obtener un catálogo completo.
| Model | LED Color | Sound Type | Frequency | Max. Volt | Volt Type | Max. Db | Size |
|---|---|---|---|---|---|---|---|
| ZT016LDCTR | Red | Continuous | 3900 | 16 | DC | 95 | 22x43.5mm |
| ZT016LDSR8R | Red | Fast Siren | 3900 | 16 | DC | 95 | 22x43.5mm |
| ZT016LDSR9R | Red | Slow Siren | 3900 | 16 | DC | 95 | 22x43.5mm |
| ZT028LACM1R | Red | Chime | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LACM1R15 | Red | 15 Sec On- Chime | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LACM1R30 | Red | 30 Sec On- Chime | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LACTB | Blue | Continuous | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LACTB15 | Blue | 15 Sec On- Continuous | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LACTB30 | Blue | 30 Sec On- Continuous | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LACTC | White | Continuous | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LACTC15 | White | 15 Sec On- Continuous | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LACTC30 | White | 30 Sec On- Continuous | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LACTG | Green | Continuous | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LACTG15 | Green | 15 Sec On- Continuous | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LACTG30 | Green | 30 Sec On- Continuous | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LACTR | Red | Continuous | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LACTR15 | Red | 15 Sec On- Continuous | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LACTR30 | Red | 30 Sec On- Continuous | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LACTY | Yellow | Continuous | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LACTY15 | Yellow | 15 Sec On- Continuous | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LACTY30 | Yellow | 30 Sec On- Continuous | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LADP2R | Red | Fast Double Pulse | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LADP3R | Red | Slow Double Pulse | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LAFP1B | Blue | Fast Pulse | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LAFP1C | White | Fast Pulse | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LAFP1G | Green | Fast Pulse | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LAFP1R | Red | Fast Pulse | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LAFP1R15 | Red | 15 Sec On- Fast Pulse | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LAFP1R30 | Red | 30 Sec On- Fast Pulse | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
Industrial Indicators with LEDs
- La alarma y el LED se controlan por separado
- Archivo UL # NKCR2.E478987
- Archivo cUL # NKCR8.E478987
- NEMA 4X, 3R y 12
- dB Distancia = 2 pies (60 cm)
- Se adapta al agujero estándar de 22 mm con chavetero
- Terminación segura a prueba de dedos
- Patente No. 9165440
Aquí encontrará algunos de los modelos más populares para esta línea, pero hay más. Clica en el botón de abajo para obtener un catálogo completo.
| Model | LED Color | Sound Type | Frequency | Max. Volt | Volt Type | Max. Db | Size |
|---|---|---|---|---|---|---|---|
| ZT028LAIC1G | Green | Continuous | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LAIC1R | Red | Continuous | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LAIC2G | Green | Fast Pulse | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LAIC2R | Red | Fast Pulse | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LAIC3B | Blue | Slow Pulse | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LAIC3G | Green | Slow Pulse | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LAIC3R | Red | Slow Pulse | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LDIC1G | Green | Continuous | 3900 | 28 | DC | 95 | 22x43.5mm |
| ZT028LDIC1R | Red | Continuous | 3900 | 28 | DC | 95 | 22x43.5mm |
| ZT028LDIC1Y | Yellow | IC Continuous | 3900 | 28 | DC | 95 | 22x43.5mm |
| ZT028LDIC2G | Green | Fast Pulse | 3900 | 28 | DC | 95 | 22x43.5mm |
| ZT028LDIC2R | Red | Fast Pulse | 3900 | 28 | DC | 95 | 22x43.5mm |
| ZT028LDIC3G | Green | Slow Pulse | 3900 | 28 | DC | 95 | 22x43.5mm |
| ZT028LDIC3R | Red | Slow Pulse | 3900 | 28 | DC | 95 | 22x43.5mm |
| ZT028MDIC1Y | Yellow | IC Continuous | 3900 | 28 | DC | 85 | 22x43.5mm |
| Red | Continuous | 3900 | 28 | AC/DC | 95 | 22x43.5mm | |
| ZT028LACTR15 | Red | 15 Sec On- Continuous | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LACTR30 | Red | 30 Sec On- Continuous | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LACTY | Yellow | Continuous | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LACTY15 | Yellow | 15 Sec On- Continuous | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LACTY30 | Yellow | 30 Sec On- Continuous | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LADP2R | Red | Fast Double Pulse | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LADP3R | Red | Slow Double Pulse | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LAFP1B | Blue | Fast Pulse | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LAFP1C | White | Fast Pulse | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LAFP1G | Green | Fast Pulse | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LAFP1R | Red | Fast Pulse | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LAFP1R15 | Red | 15 Sec On- Fast Pulse | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
| ZT028LAFP1R30 | Red | 30 Sec On- Fast Pulse | 3900 | 28 | AC/DC | 95 | 22x43.5mm |
Back-up Alarms
- Usado en equipos de construcción, equipos de manejo de materiales, vehículos de desecho y vehículos de carretera
- UL reconocido; CE aprobado
- SAE Tipos A, B, C y D
- dB Distancia = 4 pies
| Model | Sound Type | Frequency | Min. Volt | Max. Volt | Volt Type | Max. Db | Size |
|---|---|---|---|---|---|---|---|
| STA20302 | Slow Pulse | 1250 | 12 | 24 | DC | 87 | 41x84x69mm |
| STA20502 | Slow Pulse | 1250 | 12 | 24 | DC | 97 | 41x84x69mm |
| STA22702W | Slow Pulse | 1250 | 12 | 24 | DC | 107 | 51x83x83mm |
| STA32264A | Slow Pulse | 1600 | 12 | 48 | DC | 102 | 76x127x71mm |
| STA35802 | Slow Pulse | 1250 | 12 | 24 | DC | 112 | 127x100x79cm |
Contactenos Con Sus Requerimientos
Nos complacerá analizar su proyecto con usted para determinar nuestra mejor solución para sus necesidades.
